Mastervolt ChargeMaster 12

12
DIMENSIONS CHARGEMASTER 12/15-2
OUTLINE DRAWING
© Mastervolt BV, Snijdersbergweg 93, 1105 AN Amsterdam, Netherlands
Tel: + 31-20-3422100 Fax: + 31-20-6971006 Email: info@mastervolt.com
Figure 4 – Abbildung 4 –
Figuur 4 – Figura 4
All dimensions are in mm.
121
36
193
206
186
50
