Mastervolt COMBIMASTER 12V/3000VA-100A User Manual

18
CombiMaster 230V Series – User and Installation Manual
Value
Meaning
Default
Adjustable Range
Lock config.
Option to lock the configuration (installer level)
Off
On, Off
Factory reset
button
Button to restore the configuration's default values
Off
On, Off
Inverter
Energy save
mode
Option to enable Energy save mode
Off
On, Off
Frequency
Inverter frequency
50Hz
50, 60Hz
DC Low on
Voltage level at which the inverter switches on (DC Low off
alarm)
11.5 / 23.0V
10.7-12.5 / 21.4-25.0V
DC Low off
Voltage level at which the inverter switches off
10.2 / 20.4V
10.2-12.0 / 20.4-24.0V
Charger
Max charge cur.
Maximum charging current
60 / 100A
0-60 / 0-100A
Battery type
Select the battery type
Flooded
User defined, AGM,
Gel, Flooded, Li-Ion,
Constant voltage
Constant
voltage
Select the Constant output voltage
13.25V/26.5V
12-15 / 24-30V
Bulk
Voltage
Maximum Bulk voltage
14.4 / 28.8V
12-15 / 24-30V
Minimum time
Minimum time that the charger stays in bulk phase
2 min
0-600 min
Maximum time
Maximum time the bulk phase lasts before the charger
transitions to absorption
480 min
0-600 min
Start bulk time
Voltage level at which to start the bulk timer
13.25 / 26.50 V
12-15 / 24-30V
Absorption
Voltage
Absorption voltage
14.25 / 28.50V
12-15 / 24-30V
Minimum time
Minimum time that the charger stays in absorption phase
15 min
0-600 min
Maximum time
Maximum time that the charger stays in absorption phase
240 min
0-600 min
Return Amps
Return amps (% of maximum charge current)
6%
0-100%
Float
Voltage
Float voltage
13.25 / 26.50V
12-15 / 24-30V
Return to Bulk s
Delay time before the charger returns to Bulk after reaching
the Return to Bulk voltage
30 s
0-600sec
Return to Bulk V
Bulk return voltage. If the battery voltage has dropped below
this voltage, the charger will return to bulk phase
12.80 / 25.60V
12-15 / 24-30V
AC IN
AC IN support
Option to enable AC input support mode
Off
On, Off
Voltage range
AC voltage input window
Wide
Wide, narrow
AC IN limits
AC IN Limit A
Fuse pre-setting A
6A
0-30A
AC IN Limit B
Fuse pre-setting B
10A
0-30A
AC IN Limit C
Fuse pre-setting C
16A
0-30A
Dry contact (installer level)
Function
Select dry contact alarm function
Alarm, Power level
Power Level
Inverter output power level
60%
0-100%
Delay on
Delay on
5s
0-300 seconds
Delay off
Delay off
5s
0-300 seconds
DIP Switches
1234567890
0000000000
Position of the DIP switches
0
0,1
5.2.5 Events – System automation
A CZone/MasterBus device can be programmed to initiate an action at another connected device. This is very helpful in
automation of your system but is not required. In MasterBus this is done by means of event based commands. In the Events
tab you can program the CombiMaster to act as an event source. Events which occur during the operation of the CombiMaster
will then trigger actions from other products. The following tables list the parameters as shown in MasterAdjust.
