CombiMaster 230V Series – User and Installation Manual
8.4 Miscellaneous
Model
12V/2000VA-60A
24V/2000VA-40A
12V/3000VA-100A
24V/3000VA-60A
Dimensions in mm
378×284×155
378×284×155
448×284×155
448×284×155
Weight in kg
6,9
6,9
9,3
9,3
Protection degree
IP 23 vertical mounted, IP 21 horizontal mounted
Safety class
IEC protection class I
Grounding
Jumper-selectable wire bridge
Operating temperature
-25°C to 60°C, above 40°C derating
Storage temperature
-30 to 70°C
Relative humidity
Max 95% relative humidity, not condensing.
Standards, approvals & listings
CE, E-mark
Front panel display
Yes, LEDs show AC input state, Inverter state, charger state
Battery temperature sensor
Yes
Cooling
Maintenance free vario fans
Parallel stacking
No
3-phase configuration
No
MasterBus powering
Yes
LEN (Load Equivalence Number)
0
Protections
AC input
AC IN limit
Adjustable
Reverse polarity
Yes (internally fused, non-replaceable)
Frequency monitoring
Relay disconnects when frequency is out of range
Voltage monitoring
Relay disconnects when voltage is out of range
Output
Short circuit protection
Yes (inverter only)
Overload protection
Yes (integrated resettable thermal fuse)
Over temperature protection
Yes
AC backfeed protection
Yes
