27
8.5 Dimensions
12V/2000VA-60A and 24V/2000VA-40A
12V/3000VA-100A and 24V/3000VA-60A
Figure 8: Dimensions in mm [inches]
240 [9.5]
262 [10.3]
150 [5.9]
153 [6.0]
378 [14.9]
284 [11.2]
240 [9.5]
327 [12.9]
150 [5.9]
284 [11.2]
448 [17.6]
153 [6.0]
