Mastervolt MASS SINE 12/500

EN / MASS Sine 12/500 / March 2000
37
Table 1,
jumper settings:
S1 S2 mode output voltage
0 0 standard 230V
0 1 low power 208V < 30W
1 0 economic 208V < 250W
1 1 stand by 0V, switches on at load
Fig. 6: Position of the jumpers at the MASS Sine 12/500.
