three-stage charge characteristic.
The LEDs A, B, C and D represent the following
information (see figure 6 for the references
indicated between brackets [ ]):
Bulk [A]: Main charge
Batteries are charged with full charger output
current at a voltage between 12V resp. 24V and
14.4V resp. 28.8V.
Absorption [B]: absorption charge
The batteries are almost (approx. 85%)
charged. Charging continues with decreasing
current until the batteries are full.
Float [C]: “trickle charge”
The batteries accept only a small current.
Voltage is lowered to 13.2V resp. 26.4V to keep
the battery fully charged without formation of
gases.
AC present [D]:
The AC-present –LED illuminates if the charger
is in operation (230V supply).
Besides the inverter there is an external 230V
AC source available.
5.3 Adjustment of the maximum charge
current
When the available current from the AC source
is limited (for instance to avoid the shore fuse
from tripping), the output current of the charger
can be reduced (and accordingly the AC-power
consumption of the battery charger):
Press the Select button for 5
seconds until the green Select
indication LED flashes.
Press the Charger-button
shortly to display “CURRENT
CONT.”
Adjust the desired output
current (10 – 100%) by
pressing the Set-up button
If the Select button is held for
five seconds, the arrow’s
direction in the right part of the
display will change. If the arrow
is pointing downwards (È) the set value can be
changed into lower values by means of the Set-
up button. If the arrow is pointing upwards (Ç)
the set value can be changed into higher
values.
After adjusting the output
current to the desired value,
press the “Select”-button
shortly until “EXIT LEVEL” is displayed.
Now it is possible to return to
the user menu by means of the
Set-up-button. Also if none of
the buttons was used for 15 seconds the
Masterlink MICC returns to the users menu.
5.4 Adjustment of the Power sharing /
Power support level (Mass Combi
only).
When the available current from the AC source
is limited (for instance to avoid the shore fuse
from tripping), the maximum current can be
limited. In case of the Mass Combi you can
adjust the Power sharing / Power support* level.
Press the Select button for 5
seconds until the green Select
indication LED flashes.
*See chapter 7.7 of the manual of the Mass
Combi to enable Power sharing / Power support
function.
Select
Set-up
Select
Charger
CURRENT CONT.
100% Ç
Select
Select
EXIT LEVEL
->PRESS SET-UP
Set-up
