10 ADVANCED SETTINGS
After pressing and holding the Select and Set-
up buttons simultaneously for 5 seconds
several adjustments can be made to set the
Masterlink MICC according the users
requirements. However, under normal
circumstances these adjustments should not be
changed. Refer to figure 9 for more the set-up
drawing of these advanced settings. The
numbers below between brackets () correspond
with this drawing
CAREFUL!
Adjustments in the Advanced settings
menu can result in deviation in the
functioning of the MICC when
incorporated incorrectly. For more
information see also the set-up drawing.
10.1 Testing alarm function
At this level the low battery function can be
tested without draining the battery.
This menu can be entered by pressing and
holding the Select and Set-up buttons
simultaneously for 5 seconds until the Set-up
LED and the Select LED flash.
Testing alarm function (M06)
Press the Volt-Amp button to enter the menu
With the Set-up button you can toggle the alarm
function between ON and OFF, independently
of the state of charge, to test the alarm
functions.
Return to users menu (M07)
By pressing the Select button, you can scroll to
the ‘EXIT-LEVEL’ If this level is entered you can
return to the user menu by means of the Set-up
button.
10.2 Exponent adjustment
With this menu the Peukert exponent and the
C.E.F. (Charge Efficiency Factor) can be in
accordance with the type of battery installed
(refer to chapter 11 for additional information)
It is advisable to only change these setting if
extended knowledge of the installed battery is
available.
This menu can be entered by and holding the
Select and Set-up buttons simultaneously for 5
seconds until the Set-up and Select LEDs flash.
Setting the Peukert exponent (A08)
Press the Ah-Time button to enter the menu
With the Set-up button the value can be
changed from 1.01 to 1.50. The factory default
setting
is 1.27.
Note: If the Select button is held for
five seconds, the arrow in the right part
of the display will change. If the arrow is
pointing downwards (È) the set value
can be decreased by means of the Set-
up button. If the arrow is pointing
upwards (Ç) the set value can be
increased.
Setting the Charge efficiency factor (A09)
In the second the C.E.F. (Charge Efficiency
Factor) can be changed. The C.E.F. is
Select Set-up
Volt-Amp
TEST LOW BAT
OFF
Select
EXIT LEVEL
->PRESS SET-UP
Select Set-up
Ah-Time
CHANGE PEUKERT
1.27 P Ç
