16 November 2004 / Masterlink MICC / EN
Press the Charger-button
shortly to display “CURRENT
CONT.”
You can adjust the Power
sharing / Power support level
between 2.5A and 25A in steps
of a 0.5A by pressing the Set-up button.
If the Select button is held for
five seconds, the arrow’s
direction in the right part of the
display will change. If the arrow is pointing
downwards (È) the set value can be changed
into lower values by means of the Set-up
button. If the arrow is pointing upwards (Ç) the
set value can be changed into higher values.
After adjusting the output
current to the desired value,
press the “Select”-button
shortly until “EXIT LEVEL” is displayed.
Now it is possible to return to
the user menu by means of the
Set-up-button. Also if none of
the buttons was used for 15 seconds the
Masterlink MICC returns to the users menu.
5.5 Remote control of the Inverter
By pressing the “Inverter”-
switch the inverter can be
switched on and off. After a few
seconds the “Inverter”-LED illuminates when the
inverter is in operation (AC-output).
Figure 7: Set-up drawing (user level).
Set-up
Set-up
H01
Battery historical data
H01
Battery historical data
H02
Deepest Discharge
H02
Deepest Discharge
H03
Peukert Exponet
H03
Peukert Exponet
H04
C.E.F.
H04
C.E.F.
H05
Numbers of
cycles detected
H05
Numbers of
cycles detected
DEPT 6
DEPT 6
H6
Software version
H6
Software version
DEPT 5
DEPT 4
T03
Battery Capacity
Consumed read out in
Ahr
DEPT 3
T02
Time remaing
present in
hours
V02
Voltage read out
Starter battery
DEPT 2
C01
Charger switch status
ON-OFF
T01
Battery Status
present in
% full
V01
Voltage & Current
read out
Service Battery
I01
Inverter switch status
ON - OFF
DEPT 1
ChargerAhr-timeVolt-ampInverterSelect =>
MICC User level
Direct access by pressing desired function button shortly
DEPT 7
DEPT 7
H07
Error status
H07
Error status
Charger
CURRENT CONT.
25A Ç
Set-up
Select
Select
EXIT LEVEL
->PRESS SET-UP
Set-up
Inverter
