FIRST START UP
EN / MasterShunt / February 2011 13
6 FIRST START UP
At first start up with the MasterShunt installed,
MasterBus (via a MasterView display or the
MasterAdjust software) will guide you through the
following settings. See the concerning manual for
display navigation.
Variable Description Factory sett. Range
Basic set up
Language
Change the language at first start up. See chapter 5
for more instructions.
English 11 languages, see
section 14.1
Battery capacity Set the battery capacity to enable the MasterShunt
calculating the state of charge.
Value from First
Setup
30-10000Ah
Battery type Four different battery types can be selected. The
spiral battery belongs to the AGM batteries.
Value from First
setup
Gel, AGM, Wet, Li-
ion battery
Nominal voltage Nominal battery voltage, set at first set up. Value from First
setup
12V ,24V, 48V
Advanced mode
Reverse IN/OUT Use this option for reversing input and output, when
you installed the load at the left of the MasterShunt.
Off Off, On
Mode Use this option for parallel (chapter 7) or single
device configuration. “I + U only: is an option to only
measure the current and voltage with the
MasterShunt configured as single device.
Single device I + U only, Single
device, Parallel
mode.
Complete
Complete It is still possible now to check your settings. When
ready, press “Complete” to finish the first start up.
If you want to alter a first start up variable
afterwards, resetting the settings is necessary.
