8 MONITORING MENU
The main menu shows the monitoring functions
available with the MasterShunt. It offers a quick
status overview of the battery bank. None of the
displayed information can be modified at this menu.
Message Description
State Of Charge
[%]
This readout shows the actual amount of energy left in the battery, related to the battery
capacity you selected.
Remaining
[hh:mm:ss]
The time remaining before the battery will be empty. Maximum value: 480 hrs (20 days).
Under 24 hrs it shows hh:mm:ss, above that dd:hh. During charging it shows “--:--:--“.
This value depends on the current drawn.
Cap. consumed Capacity consumed shows how many Amp-hours (Ah) have been consumed from the
battery bank.
Battery [V] Shows the measured voltage at the MasterShunt.
Battery [A] Shows the measured current through the poles of the MasterShunt. Charging appears
as positive current, discharging as negative current.
Battery [°C]/[°F] Shows the temperature measured by the temperature sensor, connected to MasterShunt
For language setting American the temperature is displayed in °F. If a charger has been
connected to the MasterShunt, this temperature sensor will be relevant for charge
voltage correction!
Time If you have set the Time, this screen shows hh:mm:ss. Refer to chapter 11 for settings.
Date If you have set the Date, this screen shows dd:mm:yyyy. Refer to chapter 11 for settings.
