SPECIFICATIONS
26 February 2011 / MasterShunt / EN
15.2 DIMENSIONS
Figure 21: Dimensions in mm [inch]
NOTE: If you combine the MasterShunt with other MasterConnect devices, MasterConnect will become
130 mm [5,10 inch] longer.
NOTE: At the bottom of the MasterShunt casing the centre to centre distances of the mounting holes
and the DC fastening threads are displayed.
