MONITORING AND CONFIGURATION
EN / MasterView Easy MkII / September 2010 13
6.2 MASTERVIEW EASY CONFIGURATION
To change settings of the MasterView Easy display,
press Go To Configuration. The MasterView Easy
configuration menu is used for read out and
adjustment of settings like backlight illumination,
displayed language and number of devices.
The MasterView Easy Configuration Lock
disables configuration of all connected
devices. After selection of Configuration
Enabled the Configuration Lock symbol disappears
in all configuration groups. The first configuration
group (at Easy panel: General) always remains
enabled.
Variable Meaning Default Adjustable. range
General
Name yacht Name of the boat, the panel is installed on.
See also section 6.2.1.
Yacht name Maximum 16 characters
Device name Name of this device. This name will be
recognized by all connected devices.
DIS MV
Easy
DIS+Maximum 12 characters
Switch X Switches to use for event configuration.
Renaming the switches after their application
is recommended. X ranges 1 – 6.
Switch X Maximum 16 characters
Devices in list Devices to show in the device list. At
Selection three selection boxes appear to
choose a MasterBus device connected.
Excluded means, you can select all devices
except maximum three devices.
Selection, All, Excluded
Buzzer Switching of the buzzer.
The buzzer can also be target in the
MasterBus events, if activated it sounds for
maximum 1 minute. See also section 6.3.
This means the buzzer can sound even if
you switched it off in the configuration.
On On, Off
Auto Lock after Time after which to lock the panel. Off Off, 2, 5, 10 minutes
Backlight Choose the backlight colour. In alarm the
backlight turns red, if not red already.
White White, Red
Power save
Backlight time Time the display backlight stays illuminated
since the last button was touched.
2 minutes always off,2 minutes,5
minutes,10minutes,always on
Auto off Time after which the MasterView Easy will
be switched off since the last button touch.
1 day 1 day, 2 days,
always on
Backlight Percentage of illuminance 50% 0-100%, in 10% steps
Favourites page
Name fav. page Name of your Favourites page. - Maximum 16 characters
Favourites page Selection of areas to show. Analogue
means, a bar is shown instead of a value.
no No, analogue, 1,2,3,4,6 areas,
1-3 tanklevels
Connect to Fav
Connect to Area to connect the next item to Area 1 Area 1,2,3,4,5,6
Device Device to add the monitoring item from Select… System dependent
Group no. Group number in monitoring page selected 1 1-65535
Item no. Item number in monitoring page selected 1 1-65535
Add Add the item to the Favourites page
In Connected favour., a list of the added monitoring items for the chosen areas is shown. This list is read only in
user level.
6.2.1 Changing of characters
Changing of characters, for instance the yacht
name, is accelerated by keeping the up/down arrow
pressed. The characters change then in second
gear.
