9.2 SOLADIN WEB OUTLINE DRAWINGS
Figure 9-1 Dimensions in mm of the Soladin 1000 Web and 1500 Web
9.3 ORDERING INFORMATION
Part number Description
130000700 Soladin 700 Web
130001000 Soladin 1000 Web
130001500 Soladin 1500 Web
130500640 Soladin Web DC Switch
129
241
478
407
206
172
353.5
EN / Soladin 700/1000/1500 Web User’s Manual
|
17
