INFORMATION
EN / WHISPER 12 Ultra - Three phase for mobile applications / December 2008 / Copyright © 2008 Mastervolt 11
Fig. 5: Top View main components Whisper12 Ultra – three phase, mobile
Fig. 6: Rear view main components Whisper 12Ultra – three phase, mobile
50
56
54
55
52
53
51
51
46
47
48
40
41
42
43
44
45
40 Exhaust
41 Filler cap engine coolant
42 Rocker cover
43 Filler cap engine oil
44 Temperature switch
coolant
45 Thermostat housing
46 Failsafe
47 Air cleaner element
48 Hoist eye rear
50 Exhaust manifold (water
cooled)
51 Rubber engine mounting
52 Starter motor solenoid
53 Starter motor
54 V-belt
55 Engine coolant pump
56 Alternator (12VDC)
