Mastervolt WHISPER 12 ULTRA User Manual

INFORMATION
16 Copyright © 2008 Mastervolt / December 2008 / Whisper 12 Ultra - Three phase for mobile applications/ EN
2.5.15 Wiring codes and colours
number colour cross section
battery > starter motor red 25 mm2
starter motor > DDC 1 red 6 mm2
starter motor > LCP 13 red 2,5 mm2
battery > ground black 25 mm2
ground > LCP ground (GND) 2 black 4 mm2
DDC > glow plug 3 brown 4 mm2
DDC > starter solenoid 4 yellow 2,5 mm2
LCP > fuel lift pump + 5 brown 1,5 mm2
LCP > fuel lift pump - 15 black 1,5 mm2
DDC > LCD 5 grey 1,5 mm2
DDC > oil pressure switch 6 purple 1 mm2
LCP > oil pressure switch 6 purple/black 1 mm2
DDC > water temperature switch 7 blue 1 mm2
LCP > water temperature switch 7 blue/black 1 mm2
DDC > generator temperature switch 8 blue/green 1 mm2
LCP > generator temperature switch 8 blue/pink 1 mm2
DDC > fuel solenoid (hold) 9 green 1,5 mm2
DDC > fuel solenoid (pull) 20 pink 2,5 mm2
DDC > fuel solenoid (com.) 17 black 2,5 mm2
B+ terminal alternator > starter motor 21 red 6 mm2
DDC >R terminal alternator 18 white 1,5 mm2
DDC > L terminal alternator 19 orange 1,5 mm2
DDC > current measuring transformer AC1 66 black 1 mm2
DDC > current measuring transformer AC1 66 red 1 mm2
DDC > current measuring transformer AC2 77 black 1 mm2
DDC > current measuring transformer AC2 77 red 1 mm2
DDC > current measuring transformer AC3 88 black 1 mm2
DDC > current measuring transformer AC3 88 red 1 mm2
DDC > LCP 12 black 1,5 mm2
DDC > LCP 14 red 1,5 mm2
DDC > LCP 16 red/green 1,5 mm2
DDC > generator AC output AC1 33 brown 1 mm2
DDC > generator AC output AC1 33 blue 1 mm2
DDC > generator AC output AC2 44 brown 1 mm2
DDC > generator AC output AC2 44 blue 1 mm2
DDC > generator AC output AC3 55 brown 1 mm2
DDC > generator AC output AC3 55 blue 1 mm2
DDC=Digital Diesel Control Unit
LCP=Local Control Panel
