With the captured readings, analysis can done by referring to the limits as
indicated that MAX voltage should exceed 13.5V (max. voltage at 2,000
RPM) and MIN voltage should be more than 12.5V (min voltage during
idling speed).
After that press key again and the results will be shown as below (Fig
57.)
8. If either minimum or maximum charging volts are not within the voltage range
limits then it will display one of the screen as below (Fig.58 & 59) and it will
prompt you to check the alternator system for the fault.
11. Just press key if you need to printout the results.
Fig.57
Fig.58
Fig. 59
Results: Good
At 2,000 rpm,
Loading Test:
Average Charging
Volts: 13.3V
[Enter] to proceed
Results: Low charge
At 2,000 rpm,
Loading Test:
>13.5V: Max. 13.3V
Check for loose belt
and the alternator.
[Enter] to proceed
Results: Low charge
At 2,000 rpm,
Loading Test:
>12.5V: Min. 12.4V
Check for loose belt
and the alternator.
[Enter] to proceed
