MBT1015 rev-C
User’s Manual Versio18.08
11. If you did not follow the right procedures during the testing, it will display the
results as follows (Fig. 75) below:
12. Just press key if you need to printout the results.
13. To exit the program, pressing the key at any moment will exit and
return back to the menu screen (Fig.61).
8.0 – Stored Results
8.1 Recalling and viewing previous Test Results
To view the results of the last test, MBT1015 rev-C has to be connected to an external
power source by either clamping its clips directly to a 12Volt car battery or connected
to a PC via the USB port.
Results: Not detected
Grounding test failed!
Try again and follow
the step by step
instructions given.
Fig.75
