MBT1015 rev-C
User’s Manual Version 18.08
It also measured the diode ripple voltage during the test with results and
recommendations displayed after each test.
This test will determine
whether the alternator is performing its job properly.
4. Grounding Test:
Same as battery test, this test is also meant for 12V batteries only.
Analyses the condition of the electrical return circuit contacts resistance
which was connected to the engine or chassis body from the battery
terminal with results and recommendations displayed after testing.
1.2 Specifications:
Operating Voltage: 9V ~ 36V DC (max)
Safety: Built-in reverse polarity protection.
Analysing Capacity (Amps):
Automotive 12V Batteries: CCA/SAE: 100A ~ 2000A EN: 100A ~ 2000A
CA/MCA: 100A ~ 2000A IEC:100A~2000A
DIN: 100A ~ 2000A JIS#:100A~2000A
Motorcycle 12V Batteries: CCA/SAE: 40A ~ 600A EN: 40A ~ 600A
CA/MCA: 40A ~ 600A IEC: 40A ~ 600A
DIN: 40A ~ 600A JIS#: 40A ~ 600A
DC Volts Accuracy: ± 2% Reading
Battery analysing time: Less than 8 seconds.
Language: English, Spanish, German, French, Italian, Romanian,
Polish, Swedish, Dutch & Finnish
Memory: Stored up to 47 Test results.
PC connection: Through USB port.
Printer head: Thermo print head.
Paper width: 56.5mm 0.5mm
Paper roll diameter: 40.0 mm O.D.
Printing speed: 50 mm per second.
Working temperature: 0ºC ~ 50ºC
Working Humidity: 10 % ~ 80 %
