MBT1015 rev-C
User’s Manual Version 18.08
After completion of the input, press key will proceed to the next display
as shown in Fig. 66 below.
3. Follow the instructions given, transfer the BLACK tester clip from the battery [-]
terminal to a suitable position on the engine or chassis body leaving the RED
clip still attached to the battery [+] terminal.
4. After it has done, press key to continue (Fig. 67).
5. The Analyser will start to measure (Fig.68).
Fig.66
Grounding Test
Clip the Black clip to
engine body or the car
chassis and the Red
clip to the battery
[+] post.
Analysing ...
Please wait!
Fig.68
Grounding Test
[Enter] to proceed
Fig.67
To Next Page
