12
21: Red Stoplight
See section 7.
22:
Green Stoplight
See section 7.
23:
Grams / Ounces
Annunciator will display according to the following chart when the designated character
is in the data stream.
24:
Fairbanks Addressable
Set option 24 only if the Fairbanks indicator is sending out multiple streams, ie. gross
and tare weights. Set the option according to the chart.
Character
"G" or "g"
"N" or "n"
"L" or "l"
"K" or "k"
"M" or "m"
"Z" or "z"
Display
"G"
"N"
"L"
"kg"
"gr"
"oz"
Designator for
Gross Weight
Net Weight
Pounds
kilograms
grams
Ounces
Value
1 Scale 1
2 Scale 2
3 Scale 3
4 Scale 4/Total
5 Scale 1
6 Scale 2
7 Scale 3
8 Scale 4/Total
9 Scale 1
10 Scale 2
Addressable for
40 with 7 data bits odd parity
41 with 7 data bits odd parity
42 with 7 data bits odd parity
43 with 7 data bits odd parity
40 with 7 data bits even parity
41 with 7 data bits even parity
42 with 7 data bits even parity
43 with 7 data bits even parity
40 with 8 data bits no parity
41 with 8 data bits no parity
Value
11 Scale 3
12 Scale 4/Total
13 Scale 2
14 Scale 3
15 Scale 4
16 Scale 5
17 Scale 6
18 Scale 7
19 Scale 8
20 Sum of all Scales
Addressable for
42 with 8 data bits no parity
43 with 8 data bits no parity
46 with 7 data bits odd parity
52 with 7 data bits odd parity
58 with 7 data bits odd parity
64 with 7 data bits odd parity
70 with 7 data bits odd parity
76 with 7 data bits odd parity
82 with 7 data bits odd parity
99 with 7 data bits odd parity
