Matko SBL-2 - Fixed Annunciator; Demo Mode; Intensity;Siemens; Hardware Test

13
25: Fixed Annunciator
Option 25 will disregard the characters in the data stream and force the annunciators
on according to the following chart
26:
Demo Mode
Option 26 is used to set the display to cycle through various weights for use as a
demo unit without connecting to an indicator.
27:
Intensity
Option 27 is used to set the LED intensity to low (OFF) or High (ON). See Section 4
for an alternative way to set the intensity.
28:
Siemens
Option 28 enables the remote display to use a Siemens Milltronics BW500 Integrator
and will direct the remote into a Siemens Sub Menu. Siemens Sub Menu Options may
be downlaoded at www.matko.com/siemens
29:
Hardware Test
Option 29 enables the remote display to test the serial ports by adding jumper wires.
Test the RS232 connection with a jumper between RXD and TXD or test Current Loop
with 2 jumpers between RX CL(+) to TX CL(+) and RX CL(-) to TX CL(-). If the display
shows either “Bad 0” or “Bad 1” then there is a problem with hardware.
Value
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
SBL-2
Use Data Stream
LB - GR
KG - GR
LB - NT
KG - NT
SBL-4 and SBL-6
Use Data Stream
KG - NT
LB - NT
LB - GR
KG - GR
SBL-4A and SBL-6A
Use Data Stream
lb - G
kg - G
gr - G
t - G
T - G
to - G
pw - G
oz - G
lb - N
kg - N
gr - N
t - N
T - N
to - N
pw - N
oz - N
