Section 6: Option Details
5: No Data
Option 5 sets the display to do one of three things after a data stream time out. The default is
to display "NoData". The other two options are "Clear" (blank the display) and "Hold" (keep
the last weight sent). The time out length can be specified with Option 3. RIGHT toggles
between the three choices, "NoData", "Clear", and "Hold"
6:
Fixed Decimal Point
Option 6 will set the display to illuminate a decimal point when it is not present in the data
stream. Default (off) will show a decimal point only where it is located in the data stream. All
other values represent the digit to attach a decimal point to, starting from right to left.
Value Decimal Placement
0 Default
1 ######
2 #####.#
3 ####.##
4 ###.###
5 ##.####
6 #.#####
7:
No Count Down
Option 7 will disable the display from counting down from 9 to 0 when powered up.
8:
No Zero Suppression
Option 8 will disable the display’s ability to suppress leading "0"s with spaces. The default
(off) will display a space for all leading "0"s up to the final two in the 1s and 10s column or up
to a "0" immediately in front of a decimal point. For example when the option is off the stream
"000000" will become " 00" and the stream "0000.00" will become " 0.00".
9:
Display Alpha Characters
Option 9 will enable the unit to display both alpha and numeric characters. The default (off)
will replace all non-numerics with spaces. A 7 segment display is limited by the alpha
characters it can display. For example it can not display characters such as "x", "q", "k", "!" or
"?".
