Section 3: Quick Setup Procedures
Section 3:
Quick Setup Procedures
If possible place a weight on the scale. Wire up the display according to Section 2 and
configure the transmitting device to output continuously. Press and release the
RESET button on the display. While the display is counting down from 9 to 0 hold the
LEARN button. At the end of countdown the display will flash "LEARN" then the
BAUD rate such as 1200 and then the weight. Shift the data using the LEFT and
RIGHT buttons until the desired weight is in view.
SBL Series Specs
Power Interface
117 VAC or 12 VDC RS 232
2 Amp max 20 mA Current Loop Active/Passive
12 Watt (AVG) RS 422
26 Watt (MAX)
Protocol
8 Data bits No Parity
7 Data bits Odd Parity
7 Data bits Even Parity
300 to 19200 Baud
The SBL Series has an echo feature which will take the received data stream and echo
it out to further displays via RS 232, Current Loop or RS 422.
(To transmit RS 422 remove the 8 pin SP485 in socket U5 and place it in U8)
The echo feature transmits every other data stream unless option 4 is enabled.
See Section 6 for more details.
