Section 7: Stoplight
Section 7:
Stoplight
Axle System Programming
There are three types of programs to select from to control traffic to receive axle weights and totals.
• A simple Axle Scale
• An Inbound Truck Scale (driving on)
• An Outbound Truck Scale (driving off )
The general rule for all systems is a green light means the remote is ready to accept the next axle.
A red light means to come to a stop when the next axle is in position.
Axle Scale Program – Use only with axle scales
Set Option 21 = 0
Set Option 22 = 6
Sequence of Operations
• Scale is at zero with a green light.
• Truck pulls on first axle. The light will turn red signaling to stop when the axle is in position.
Once stable it will display “A-1” for axle 1 then will show the weight.
• The light will turn green to signal ready for next axle.
• Truck will pull on each additional axle on the scale one at a time. The light will turn red to signal stop
when axle is in position, display “A-N” for the axle number then the weight.
• After the last axle is weighed and the truck pulls off the display will show “total” then the total weight
of all axles.
• The system will then reset for the next truck with a green light.
Inbound Truck Scale Program – Use with a full truck scale
Set Option 21 = 0
Set Option 22 = 7
Sequence of Operations
• Scale is at zero with a green light.
• Truck pulls on first axle. The light will turn red signaling to stop when the axle is in position. Once
stable it will display “A-1” for axle 1 then will show the weight.
• The light will turn green to signal ready for next axle.
• Truck will pull on each additional axle on the scale one at a time. The light will turn red to signal stop
when axle is in position, display “A-N” for the axle number then the weight.
• After the last axle is weighed and the truck remains on the scale. The display will show “total” then
the total weight of all axles.
• The system will then reset for the next truck with a green light.
Outbound Truck Scale Program – Use with a full truck scale
Set Option 21 = 0
Set Option 22 = 8
Sequence of Operations
• Scale is at zero with a green light.
• Truck pulls all the way onto the scale. The light will go red signaling stop when in position. After the
scale is stable it will display “total” then display the total weight.
• The light will turn green to signal ready to remove the next axle.
• Truck pulls off first axle. The light will turn red signaling to stop when the axle is in position. Once
stable it will display “A-1” for axle 1 then will show the weight.
• Truck will pull off each additional axle on the scale one at a time. The light will turn red to signal stop
when axle is in position, display “A-N” for the axle number then the weight.
• After the truck pulls off the scale and the last axle is displayed the system will reset and the light will
turn green.
