PROTON 206/308 V1 System Manual 15
Relevant Topics:
1. “Class Of Service (COS)” 36
2. “Remote Alarm” 67
Allowed and Denied Lists
What’s this?
Allowed and Denied lists is a group of number strings. The PROTON 206/308 uses these lists to support two
different features viz. Toll Control and Dynamic Lock.
Association of Allowed and Denied lists with Toll Control:
When the number is dialed from a station, the PROTON 206/308 compares the dialed number string with the
number strings in allowed and denied lists.
Association of Allowed and Denied Lists with Dynamic Lock:
If the user locks the station and thereafter dials a number from his station, the PROTON 206/308 compares the
dialed number string with the number strings in allowed and denied lists for the locked status.
How it works?
• Maximum 10 Allowed and Denied Lists (level) can be formed.
• Each level accommodates 12 allowed strings and 12 denied strings.
• Each number string can have maximum of 16 digits.
• Number string can be a complete telephone number, area code or few initial digits of a telephone number.
• An allowed-denied list (a level) should be assigned to each station depending upon the requirement.
Level Allowed String Denied String
0 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
1 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
2 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
3 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
4 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
5 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
6 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
7 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
8 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
9 Num0, Num1, Num2…. Num11 Num0, Num1, Num2…. Num11
To l l
Control
Dyna mic
Lo c k
Allowed List
And
Denied List
