74 PROTON 206/308 V1 System Manual
How to program?
Step 1: Decide the toll control to be programmed station wise.
Step 2: Assign appropriate allowed-denied list (level) as per the requirement to a station using command 32.
Commands
Step 1
Take a pen and a paper. Write down the toll control to be assigned to each station.
Step 2
Use following command to assign toll control to a station:
32-Station-Daytime Level-Nighttime Level
Where,
Station is from 21 to 28.
Daytime Level is from 0 to 9.
Nighttime Level is from 0 to 9.
Use following command to assign same toll control to all stations:
32-*-Daytime Level-Nighttime Level
Few examples:
• Station 28 is to be restricted from dialing all STD numbers except to branches at Calcutta and Bangalore.
Calcutta branch number is 033-23456789 and Bangalore branch number is 080-29876543. Use level 3 for
this Toll Control.
• Station 25 is to be restricted from calling mobile phone, short distance calls (95), STD and trunk booking
services (181) in day time. But it should be allowed to dial all these numbers in night time.
Level ‘2’ allows all the calls except ISD calls.
Relevant Topics:
1. “Allowed and Denied Lists” 15
2. “Dynamic Lock” 47
Troubleshooting
PROTON 206/308 is not turning ON
• Please check the Mains Power.
• Please check the Switch.
• Please check the Main Fuse (3.15mA).
• Please check the MOV (275/14).
Command Meaning
252-3-0-03323456789-Flash Level3, allowed string location 0=Calcutta Number
252-3-1-08029876543-Flash Level3, allowed string location 1=Bangalore Number
252-3-0-0-Flash Level3, denied string loaction 0-'0' (STD Code)
32-28-3-3 Station 28 assigned level 3 for day and night
Command Meaning
253-3-0-98-Flash Level3, denied string location 0='98' (mobile code)
253-3-1-181-Flash Level3, denied string location 1='181'
253-3-2-0-Flash Level3, denied string location 2='0'
253-3-3-95-Flash Level3, denied string location 3='95'
32-25-3-2 Station 25 assigned level 3 for day and level 2 for night
