6.1 USING ENGINEERING MODE
To enter Engineering Mode, hold the LEVEL UP and DOWN keys for 3-5 seconds until Manager Mode appears on the middle LED display.
Press the LEVEL UP or DOWN key to scroll to Engineering Mode. Press ENTER to go into Engineering Mode.
CODE DEFAULT OPTIONS DESCRIPTION
Disable Errors No Yes or No No - Shows A-C class error codes.
Yes - Shows only C class error
codes.
Speed Units Mile Mile or Kilometer Set for Mile or Kilometer.
Machine Type A5x-04 A5x-02, A5x-03, or A5x-04 A5x-02 - Double incline motor, non
self power frame.
A5x-03 - Double incline motor, self
powered framed.
A5x-04 - Single incline motor, self
powered frame.
Power Save Time 30 Seconds 30-60 Seconds Power saving time for the self
powered frame.
Pause Time 30 Seconds 15 - 120 Seconds For non self powered frames only.
Not used on this model.
Serial Number N/A N/A Serial Number input is available for
both the Console and Frame. Use
the number keys and UP / DOWN
LEVEL keys to enter Engineering
Mode. Due to the limited LED
charactors, 2 layers are used to enter
the serial number. First Layer:
- PPPPP V
- PPPPP is the product name.
- V is the version. If the version is
A, just leave this blank.
Second Layer
- YY MM nnnnn.
- YY is the year (11, 12).
- MM is the month (e.g. 08, 09,
10).
- nnnnn is the actual serial
number.
Use the UP / DOWN LEVEL keys to
navigate the layers and the number
keys to input the serial number. The
product name is dependent on the
Machne Type setting.
For example, the console is EP93
with ver. A and the manufactured
date is 2011.08 with 98765. The
frame is EP308 with ver. A and the
manufactured date is 2011.06 with
12345. Their serial numbers are:
Console SN: EP93 1rst layer,
110898765 2nd layer.
Frame SN: EP308 1rst layer,
110612345 2nd layer.
Club ID N/A N/A This sets the club ID for clubs using
Asset Management.
Incline Tuner Top 98
Bottom 2
Top 74.5-99.9
Bottom 0.1-25.5
Adjusts the min / max ends of
the incline. DO NOT USE THIS
SETTING UNLESS YOU ARE A
QUALIFIED TECHNICIAN.
Sleep Time Off Off or On (1-30 Minutes) If there is no use of the machine over
a period of time, the console LEDs
will turn off (go into sleep mode).
Audio Source Off Off / TV / PC TV / External TV Manual setting that that sets
which outside TV will have audio
through the console audio ports.
CHAPTER 6: ENGINEERING MODE
