66
10.3 ASCENT TRAINER ASSEMBLY STEPS - CONTINUED
Torque this bolt to 80 N-m.
STEP 4 - GREEN / YELLOW HARDWARE BAG
CHAPTER 10: ASCENT TRAINER SPECIFICATIONS AND ASSEMBLY GUIDE
