10.1 CLIMB MILL SPECIFICA
TIONS
CHAPTER 10: CLIMB MILL SPECIFICA
TIONS
AND
ASSEMBL
Y GUIDE
FEA
TURES
Step Height
10"
Contact and T
elemetric Heart Rate Sensors
Ye
s
Ultra Non-Slip Grips
Ye
s
Handlebar Design
Ergonomically designed handrails and horn.
Thumb Switch Controls
Ye
s
RESIST
ANCE SYSTEM
T
echnology
ECB with flywheel
Power Requirements
100V - 240V - 50 / 60 HZ
AC
Minimum W
atts
N/A
78
80
Table of Contents
Default Chapter
2
Table of Contents
2
CHAPTER 1: Serial Number Location
4
CHAPTER 2: Important Safety Instructions
6
Read and Save These Instructions
6
Electrical Requirements
7
Locating the Unit
8
Chapter 3: Preventative Maintenance
9
Recommended Cleaning Tips
9
Care and Maintenance Instructions
10
CHAPTER 4: Console Overlay and Workout Description
11
Console Description
11
Workout Setup Steps - Manual
12
Workout Setup Steps - Level Based Programs
12
Workout Setup Steps - Fitness Test
13
Workout Setup Steps - Target Heart Rate
14
Workout Setup Steps - Constant Watts
14
Workout Tracking Instructions
14
USB Charging Instructions
14
CHAPTER 5: Manager Mode
15
Manager Mode Overview
15
CHAPTER 6: Engineering Mode
17
Engineering Mode Overview
17
CHAPTER 7: SERVICE Mode
18
Service Mode Overview
18
Test Mode Overview
19
CHAPTER 8: Troubleshooting
20
Electrical Diagram
20
LCB Error Indicators
29
Error Code Troubleshooting - 0149 (01AC)
31
Error Code Troubleshooting - 01AF
32
Error Code Troubleshooting - 02A0
33
Error Code Troubleshooting - 02BE / 02BF
34
Error Code Troubleshooting - 02C0
35
Error Code Troubleshooting - 02C1
36
Error Code Troubleshooting - 02C3
37
Error Code Troubleshooting - 02C5
38
Error Code Troubleshooting - 02C7
38
Error Code Troubleshooting - 04A0
39
Error Code Troubleshooting - 04B0
40
Troubleshooting - no Power to the Console
41
Troubleshooting - Heart Rate Issues
42
Troubleshooting - Toggle Issues
45
CHAPTER 9: PARTS Replacement Guide
48
Side Cover Replacement
48
Console Replacement
50
Console Overlay / Keypad Replacement
51
Front Shroud Replacement
55
Lower Control Board (LCB) Replacement
57
Upper Handlebar Replacement
58
Lower Handlebar Replacement
60
Handlebar Service
61
Stair Replacement
62
Drive Set Replacement
64
Chain Replacement
66
Brake Replacement
68
Fan Replacement
69
ECB Belt Replacement
70
Drive Belt Replacement
71
ECB Replacement
72
Speed Sensor Replacement
74
Proximity Sensor Replacement
75
IR Sensor Replacement
76
Testing the Climb Mill
78
CHAPTER 10: Climb Mill Specifications and Assembly Guide
79
Climb Mill Specifications
79
Assembly Hardware
80
Climb Mill Assembly Steps
81
Stabilizing the Climb Mill
85
CHAPTER 11: Software Upgrade Procedure
86
Software Upgrade Procedure for UCB
86
Software Upgrade Procedure for LCB
87
