8.14 TV TROUBLESHOOTING - TV WILL NOT TURN ON
CHAPTER 8: TROUBLESHOOTING
1) Remove the console back and check the electrical connections for the TV (Figures A & B).
2) If internal electrical connections are good (the console turns on), and the outlet is outputting 120V, the issue is likely with the integrated TV.
Replace the console.
FIGURE C
FIGURE BFIGURE A
