Care and Maintenance
Before beginning any care or maintenance,
you should always disconnect the
appliance from the electricity supply, and
also turn off the water supply.
Door seals
Wipe the dishwasher door seals regularly
with a damp cloth to remove
any residues.
Filters
You should clean the filters at least once a
month.
1. Remove the lower basket.
2. Turn the microfilter anticlockwise and
then lift it out as in figure 13.
3. Remove the coarse filter from the
microfilter (figure 14).
4. Remove the base filter from the
dishwasher compartment (figure 15).
You should clean and rinse the filters
thoroughly before replacing all the
sections in reverse order to that above.
The microfilter should lock into place
once it is secure as shown in figure 16.
fig. 15
fig. 16

Matrix MW401 Specifications

General

Door color	Not applicable
Built-in display	Yes
Appliance placement	Fully built-in
Control panel color	Stainless steel
Cycle time	160 min
Noise level	52 dB
Delayed start timer	-
Dishwashing programs	Eco, Intensive, Pre-wash
Number of place settings	12 place settings
Number of washing programs	4
Washing class	A
Annual water consumption	3360 L
Annual energy consumption	273 kWh
Current	13 A
Power consumption (off)	0.05 W
Water consumption per cycle	12 L
Energy consumption per cycle	0.95 kWh

Weight and Dimensions

Width	- mm
