Fitting the integrated
appliance door
Where non-standard integrated appliance
doors are supplied, additional fitting
instructions are required to ensure
compatibility with this product.
The machine is supplied with a fitting
template and these instructions should be
followed as normal.
However, the fitting template needs to be
located lower down the fascia door; this is
shown below.
The amount of offset, Y, depends on
the height of the fascia door and can be
calculated as X = 723mm.
For example, if you have a 731mm tall
fascia door and are fitting a door to your
dishwasher, then Y = 731-723 = 8mm.
Ensure that the hinge tensioners are
adjusted to balance the weight of the door.
Fitting template
Y offset
X Door height

Matrix MW401 Specifications

General

Door color	Not applicable
Built-in display	Yes
Appliance placement	Fully built-in
Control panel color	Stainless steel
Cycle time	160 min
Noise level	52 dB
Delayed start timer	-
Dishwashing programs	Eco, Intensive, Pre-wash
Number of place settings	12 place settings
Number of washing programs	4
Washing class	A
Annual water consumption	3360 L
Annual energy consumption	273 kWh
Current	13 A
Power consumption (off)	0.05 W
Water consumption per cycle	12 L
Energy consumption per cycle	0.95 kWh

Weight and Dimensions

Width	- mm
