Matrix MW401 User Manual

22
Installation
•Do not install this appliance if it is
damaged in any way. Installing a
damaged appliance may invalidate the
warranty.
•The water supply tap should be located
in an adjacent cupboard so that it can be
accessed after installation.
•Ensure the appliance is level by adjusting
the feet as necessary.
The dishwasher is equipped with an
adjustable rear foot that can be raised
or lowered by means of an adjustment
screw, located in the centre of the kick
plate.
•Only use the water inlet supplied with
the appliance.
• If the water pressure is above 10 bar, a
pressure relief valve should be used.
• After connecting the water supply, check
to ensure there are no leaks.
•The water outlet can either be connected
to a water drain or to a sink outlet spigot.
This connection should be at a minimum
of 50 cm and a maximum of 110 cm from
the floor. The drain hose should be no
longer than 4m in length to ensure good
performance from the dishwasher.
fig. 19
fig. 17
fig. 18

Matrix MW401 Specifications

General

Door color	Not applicable
Built-in display	Yes
Appliance placement	Fully built-in
Control panel color	Stainless steel
Cycle time	160 min
Noise level	52 dB
Delayed start timer	-
Dishwashing programs	Eco, Intensive, Pre-wash
Number of place settings	12 place settings
Number of washing programs	4
Washing class	A
Annual water consumption	3360 L
Annual energy consumption	273 kWh
Current	13 A
Power consumption (off)	0.05 W
Water consumption per cycle	12 L
Energy consumption per cycle	0.95 kWh

Weight and Dimensions

Width	- mm
