Matrix MX-T3x Service Manual

41
7.2 Rear roller removal
Figure A
Figure B
1. Turn off power and disconnect the cord
from the machine
2. Remove one of the end caps using a
screwdriver (Figure A)
3. Remove both roller adjustment screws using an
8mm hex-tip tools ( Figure B and C)
4. Remove roller from running belt
(Figure D and E)
Figure C
