49
7.9 Inverter removal
1. Remove shroud as outlined in section 8.1
2. Disconnect connect wires from the inverter
connections total (Figure A)
3. Remove two inverter mounting screws using
screwdriver and 6mm hex-tip tools (Figure B)
Figure A
Figure B
