44
7.4 Deck removal
Figure A
Figure B
Figure C
1. Remove the front shroud as outlined in
section 8.1 and 8.3 side rail removal.
2. Remove eight deck screws using a
5mm hex-tip tools (Figure A)
3. Remove deck from the running belt
(Figure B and C)
4. Be careful not to pinch fingers during
removal/installation of deck board
5. *New deck surfaces must ALWAYS be
matched to a new running belt*
