Matrix SATATYA Devices Manual 27
HVR Rear Panel Controls
Interface Description
HVR
1624P
HVR
1624S
HVR
0824P
HVR
0824S
HVR
0408P
HVR
0408S
Power
To connect Power
Supply 12VDC or
AC
Yes (7A) Yes (5A) Yes (7A) Yes (5A) Yes (2A) Yes (2A)
Reset
Press and hold
down the reset
button for atleast
4 seconds to
default the
following
parameters.
• LAN Settings
• User Settings
• General
Settings
• Resolution
Settings
Yes Yes Yes Yes No No
ALARM IN
To connect a
sensor device to
detect alarm
events.
Yes(8) Yes(4) Yes(8) Yes(4) Yes(2) No
ALARM OUT
To connect an
alarm sounding
relay device such
as a hooter or
siren.
Yes(3) Yes(1) Yes(3) Yes(1) Yes(1) No
Remote
Extender
To connect a
Remote IR
Receiver.
Yes No Yes No Yes No
RS 485
The PTZ cameras
can be connected
to the A and B
ports of device in
RS485 loop. The
dip switches on
the PTZ cameras
are used to set
the RS485
address of the
cameras.
Yes Yes Yes Yes Yes No
HDMI 1
(MAIN)
To connect a high
definition digital
monitor or TV for
Main view.
Yes Yes Yes Yes Yes No
HDMI 2
(SPOT)
To connect a high
definition digital
monitor or TV for
Spot view
Yes No Yes No No No
