Powering the SATATYA device
The ampere ratings of adapter for the all the SATATYA devices has been classified in the following tables.
When the power jack is connected to the device, the power LED illuminates. In the event of disconnecting the
power jack of the adapter, the LED gets off.
After completing all the necessary steps, you can power up the device.
The SATATYA device is also equipped with a Real Time Clock with on board Battery backup.
• The battery in HVR is a 3VDC/ 220 mAh (Li/MnO
2
) Lithium or Manganese Dioxide Coin Battery (CR 2032-
Non Rechargeable). The diameter is 20mm and height is 3.2mm.
• The battery in NVR24P is a 3VDC/ 18 mAh (Li-Al) alloy-Manganese Dioxide Coin Battery (ML 1220-
Rechargeable). The diameter is 12.5mm and height is 2.0mm.
• The battery in NVR8S is a 3VDC/ 220 mAh (Li/MnO
2
) Lithium or Manganese Dioxide Lithium Battery (CR
2032-Non Rechargeable). The diameter is 20mm and height is 3.2mm.
• The battery in NVRX is 3VDC/ 11 mAh (Li) Lithium Coin rechargeable battery. The diameter is 9.5mm and
height is 2.1mm.
The battery is located on the device board and should be replaced only by authorised service personnel.
Power supply for the system must be separate from other heavy electrical loads like Air-conditioners, heaters,
welding machines, electrical motors, etc.
To Power on NVRX
Variants
NVR0801X/
NVR1601X
NVR1602X/
NVR3202X
NVR3204X/
NVR6404X
NVR6408X
Power Supply 12VDC, 5A 12VDC, 5A AC supply AC supply
To Power on other
NVR Variants
NVR
8S
NVR16S
NVR
24P
NVR16H
NVR
64P/S
Power Supply 12VDC, 2A 12VDC, 5A 12VDC, 5A 12VDC, 7A AC supply
To Power on
HVR Variants
HVR
1624P
HVR
1624S
HVR
0824P
HVR
0824S
HVR
0408P
HVR
0408S
Power Supply 12VDC, 7A 12VDC, 5A 12VDC, (7A 12VDC, 5A) 12VDC, 2A 12VDC, 2A
