Matrix SATATYA NVR6404X - Page 61

Matrix SATATYA Devices Manual 55
TOP
COVER
SCREWS
FRONT VIEW
FRONT VIEW
29.46 mm
153.00
69.06 mm
360.00
TOP VIEW
LEFT VIEW
Top Cover Screws on
Left Panel
Top Cover Screws on
Right Panel
RIGHT VIEW
29.24 mm
153.00
8.90 mm
46.45
