Matrix SATATYA NVR6404X - Page 63

Matrix SATATYA Devices Manual 57
1.9 2 m m 12.75
39.57 mm265.00
TOP VIEW
RIGHT VIEW
39.72 mm
265.00
LEFT VIEW
Top Cover Screws
Side Clamps for
Rack Mounting
REAR VIEW
