Matrix SATATYA Devices Manual 69
3. Now place the Clamp fitted with the Hard Disks on the bottom plate.
NVR3204X/NVR6404X
4. Fix the clamp fitted Hard disks on the bottom plate with screws available at the rear and side panel.
Maximum torque to be applied for tightening the screws is 3 kgf.cm. Applying more than specified torque will
cause a damage to the HDD and the clamp.
Hard Disk
Clamp
Top
Cover
Side Panel
Screws
Front
Cover
Bottom
Plate
