20
STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES
PART 7: PLASTICS ASSEMBLY
ID DESCRIPTION QUANTITY
33 Front Shroud 1
34 Rear Shroud (Not shown) 1
ASSEMBLY
Install the weight stack shrouds as shown.
33
Position hangers in their lowest position
