60 Appendix B: Technical reference
Environmental specifications
• For indoor use only.
• Maximum altitude: 2000 meters.
• Operating temperature: 0 to 45 C (32 °F to 113 °F)
1
.
• Ventilation requirements: Natural convection.
• Pollution degree: 2 environment.
• Over-voltage category: I
• Ingress protection rating: IP67.
Mechanical specifications
Dimensions
1. Under current testing conditions.
GTX2000, GTX2000C, GTX5000, GTX5000C, GTX8000, GTX8000C, GTX12000, GTX12000C, GTX16000,
GTX1600C
Connectors M12 8-pin (female) X-coded connector for 100/1000 BaseT Ethernet.
M12 12-pin (male) connector for VGA/USB.
M12 12-pin (female) connector for digital I/O and power.
Certification IP67
Dimensions GTX2000, GTX2000C, GTX5000, GTX5000C,
GTX8000, GTX8000C, GTX12000,
GTX12000C, GTX16000, GTX16000C
Weight 407 g (14.35 oz) without IP cap
504 g (17.77 oz) with IP cap
Smart camera length (without the connectors) 75 mm (2.95") ± 2 mm (0.079")
Smart camera height (without the lens) 57 mm (2.24") ± 2 mm (0.079")
Smart camera width 75 mm (2.95") ± 2 mm (0.079")
IP cap length (total length) 71 mm (2.79") ± 2 mm (0.079")
IP cap max lens internal clearance
Length (interior from the mounting
flange to inside the clear top)
56.69 mm (2.23") ± 2 mm (0.079")
Diameter 48 mm (0.71") ± 2 mm (0.079")
