Appendix B: Technical reference
The Power and User LEDs typically display one of the following sets of colors:
The Status LED typically displays one of the following sets of colors:
100/1G LED typically shows the connection status of your Matrox Iris GTX:
LED color Description
Power User
Off Off Matrox Iris GTX has no power.
Orange
Orange/Red blink
Thermal trip has been detected.
Orange Off BIOS execution is in progress.
Green
Orange/Off blink
Overheating was detected. Temperature is above the throttle temperature
limit.
Green
Off
Operating System is loading.
Green
Orange
Operating system startup is in progress.
Green
Green
Camera is ready.
LED Color Description
Off There is no power or there is an internal error.
Red/Orange The image sensor is initializing.
Red/Orange blink The image sensor is not detected.
Orange Matrox Iris GTX is in an idle state. A MIL or Matrox Design Assistant application could
also be waiting for a trigger.
Green Matrox Iris GTX image acquisition is in progress.
LED Color Description
Off There is either no activity or a low speed (10 Mbits) connection between your Matrox
Iris GTX and the network.
Solid yellow There is a link on the 100 Mbits/sec connection.
Blinking yellow The 100 Mbits/sec connection has activity.
Solid green There is a link on the 1 Gbit/sec connection.
Blinking green The 1 Gbit/sec connection has activity.
