Chapter 2: Powering and connecting to your Matrox Iris GTX
Optionally connecting a liquid lens
If using a Varioptic Caspian C-39N0-160-I2C or C-39N0-250-I2C lens, it must
be connected to your Matrox Iris GTX’s liquid lens connector.
To do so, perform the following steps:
1. Disconnect the power from your Matrox Iris GTX.
2. If in place, unscrew the IP lens case from your Matrox Iris GTX.
IP lens case
Varioptic
Caspian lens
Matrox Iris GTX
Liquid lens
connector
Liquid lens
cable
Unused
cable
