Chapter 6 Maintenance
- 41 -
[WO-8525]
Maintenance item Description
Discharge of dust from dust
tube
Discharge the dust that has clogged in the dust tube.
Remove the dust cap on the bottom of the dust tube and discharge the dust.
After discharging, be sure to refasten the dust cap securely.
During continuous operation, the surface of the exhaust filter case
reaches high temperatures (exceeding 130°C). Avoid
with the skin.
Temperature confirmation
Confirm whether dry temperature is controlled at the setting temperature of
controller.
＜Confirming method＞
In case of dry temperature
1. After pushing the SV switch of the controller once, do the『ＳＶ』
light up and confirm a setting value with dry temperature.
2. Pressing SV
switch, do display the dry temperature and compare it with the
setting value.
3. If the setting value is a degree as±2～3℃, the dry temperature is normal.
Exhaust filter case
Dust tube
Dust cap
To Next Page
