Matsui MGD-15J - Default Chapter; Table of Contents

Contents
- Ⅰ -
[WO-8525]
The chapters identified with the mark contain critical
information. You must carefully read and well understand them
before you can start using MATSUI GLOBAL DRYER.
Product Warranty
Contents ···································································································· I - II
Chapter 1 Safety Precautions
1. Hazardous level marks and their Meanings -------------------------------------- 1
2. Safety Precautions
--------------------------------------------------------------------- 2
Chapter 2 Explanation Equipment
1. Overview of the equipment ---------------------------------------------------------- 5
2. The packing confirmation ------------------------------------------------------------ 5
3. Outer dimensions
--------------------------------------------------------------------- 7
4. Name of each part -------------------------------------------------------------------- 8
5. Name and the function of each controller part
--------------------------------- 9
6. Wiring diagram to level sensor for the collective unit at end of the convey 10
7. Precautions every unit equipment -------------------------------------------------- 11
Chapter 3 Installation
1. Installation for equipment -------------------------------------------------------- 13
2. Power Supply Connection
--------------------------------------------------------- 16
Chapter 4 Preparation for Operation
1. Inspecting inside of the hopper --------------------------------------------------- 17
2. Condition confirmation of each unit and feeding of the resin
-------------- 17
3. Controller setting
-------------------------------------------------------------------- 20
4. Setting the overheat Protector
----------------------------------------------------- 31
5. Jet clone operation explanation
--------------------------------------------------- 32
6. Outline of Aero Power Hopper --------------------------------------------------- 33
Chapter 5
Operating Procedures ------------------------------------------------------------ 38
