Chapter 9 Technical Manual
- 59 -
[WO-8525]
1. The shipment setting value for the controller
The parameter for the user setting mode
Of pushing SV switch every, the parameter indicator switches over. But when pushing SV switch more than
5 seconds, changes to the engineering setting mode. Be careful.
Use Character Setting range
Initial
setting value
Dry temperature SV
0
～
130
℃
(Standard)
80℃
0
～
160
℃
(High temperature)
Start-up timer
dLY
0.0
～
99.5 hour
0.0
NO.1 Convey time Fd1 0～999 sec.
20 (MGD-15
～
150)
25 (MGD-200
～
300)
NO.2 Convey time Fd2 0～999 sec.
15 (MGD-15
～
150)
25 (MGD-200
～
300)
NO.3 Convey time Fd3 0～999 sec.
15 (MGD-15
～
150)
25 (MGD-200
～
300)
NO.1 Discharge time
dc1
0
～
999 sec.
25
NO.2 Discharge time
dc2
0
～
999 sec.
25
NO.3 Discharge time
dc3
0
～
999 sec.
25
NO.2 Raw material beginning time
bt2
0
～
99 sec.
2
NO.3 Raw material beginning time
bt3
0
～
99 sec.
2
The parameter for the engineering setting mode
When pushing SV switch more than 5 seconds, changes to the engineering setting mode. Of pushing SV
switch every by the engineering setting mode, the character switches over.
Use Character Setting range
Initial
setting
value
Upper limit temperature alarm detection delay time
ULt
0
～
999 sec.
5
Feed 1 Convey malfunction detection count
LCt
0
～
999 count
50
Dry unit level gage malfunction count
FCt
0
～
999 count
20
Feed 1 Convey malfunction detection delay time
1Ed
0
～
999 min.
120
Feed 2 Convey malfunction detection delay time
2Ed
0
～
999 sec.
180
Feed 3 Convey malfunction detection delay time
3Ed
0
～
999 sec.
180
Upper limit temperature alarm
(dry temperature deviation)
dUS 0～40℃ 10
Upper limit temperature alarm
(regeneration temperature deviation)
rUS 0～40℃ 0
Dry system broken detection time (dry)
dLP
0
～
999 min.
0
Regeneration system broken detection time
(regeneration)
rLP 0～999 min. 0
Feed1 Level switch demand delay
L1d
0
～
999 sec.
3
Feed2 Level switch demand delay
L2d
0
～
999 sec.
3
Feed3 Level switch demand delay
L3d
0
～
999 sec.
3
