Matsui MGD-15J - 10．Lower Limit Level Alarm Switch; 11．It Installs DIGI-PECA Switch

Chapter 11 Options
- 79 -
[WO-8525]
10
．
Lower limit level alarm switch
With lower limit level alarm switch to be installing in the hopper, we report material low level.
Use with the option of alarm indicator light(Rotating lamp､Laminating lamp).
11
．
It installs DIGI-PECA switch
By installing DIGI-PECA switch (sold separately), when not using secondary conveying of visceral, too,
opening and shutting control of push damper can be done.
Referential remnant
MGD-15J
7.5 L
MGD-25J
MGD-50J
16 L
MGD-75J
MGD-100J
30 L
MGD-150J
MGD-200J 70 L
MGD-250J
115 L
MGD-30J
Lower limit level
alarm switch
DIGI-PECA switch
Push damper
(L)
[3]
6
TR
2
60s.
[1]
TR-2
5
S-2
切
入
ONOFF
LV-4
45
[2]
R21 S10
LOW LEVEL SWITCH
DELAY TIMER
1
S10
POWER OF DIGI-PECA
