BLADE
2-4
TI215G0010
General Information - Safety
PICTOGRAMS OF PROHIBITION
These are circular signs, with an outer red band, on a
white background, and with the symbol in black.
Prohibition of working on the machine
Prohibition of having pressure in the
container
Prohibition of having voltage
PICTOGRAMS OF OBLIGATION
These are circular signs, on a blue background and the
symbol in white.
Obligation to read the Instruction Manual
before carrying out any operation on the
machine
Obligation to use individual protective
means against noise
PICTOGRAMS OF INDICATION
These signs may vary in shape and they give useful
information.
Rotation direction
Lifting point
Possibility to carry out work
Water inlet
Water outlet
Condensate drain
COMBINATION OF PICTOGRAMS
The combination of pictograms shown above means:
Warning! Please refer to the Instruction Manual
before starting any activity.
